XVR301-04U3-P4
4 HDDs 32-Ch 2U Digital Video Recorder.
Support H.265/H.264 video formats
Support audio over coaxial cable (TVI & Uniview CVI protocol cameras)
Support TVI, AHD, CVI, CVBS, IP cameras with adaptive access
32-channel BNC input
Support 1-ch CVBS output, 1-ch VGA output, 2-ch HDMI, HDMI2 output at up to 4K (3840 x 2160)
HDMI1 and VGA simultaneous output, HDMI2 and HDMI1/VGA independent output
Long transmission distance over coaxial cable
Support mainstream cameras of ONVIF and RTSP protocol
channels
32-channel BNC input
videoCompression
Ultra 265/H.265/H.264
resolution
8MP Lite/5MP Lite/4MP Lite/1080P/720P/D1"
recordingBandwidth
N/A
storageCapacity
Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature)
networkInterface
2 RJ45 10 M/100 M/1000 M self-adaptive Ethernet Interface
powerSupply
AC 100 ～ 240 V
dimensions
442.0mm × 435.9mm × 88.6mm (17.4" × 17.2" × 3.5")
